•Bidirectional RS-232 port for universal display control — The MLC 104 Plus has a dedicated port for communicating with virtually any projector or flat panel display via bidirectional RS-232. Control drivers can be downloaded or created using the intuitive software.
•Three digital I/O ports — Each one is configurable as a digital input or digital output and can interface with a variety of devices, such as sensors, switches, LEDs, and relays.
•Dedicated IR Port — For control of IR-controllable display devices and source equipment, such as VCRs and DVD players
•Free Global Configurator software makes setup easy for non-programmers — Step-by-step menus enable fast and simple setup when combined with our extensive library of pre-written device drivers that are available on the Extron Web site.
•Enhanced function scheduling and device monitoring — Allows any controller function, such as display on or off, to be scheduled by day and time.
•IR learning capability — For capturing IR remote codes from a device's handheld remote control
•Discrete ON and OFF display power controls — Simplifies system operations and eliminates the need for an external display remote.
•RS-232 port for MediaLink Switcher support — For controlling an optional Extron MediaLink Switcher.
•Inactivity timer for display shutoff — Adjustable timer controls automatic shutdown to conserve energy, prevent plasma burn-in, or extend projector lamp life.
•Front panel security lockout — When the security lockout mode is engaged, the MLC 104 Plus's front panel becomes inoperable unless a user-defined PIN number is entered. No controller functions can be activated.
•Configurable buttons — Can be assigned to trigger a variety of functions such as selecting an input or sending a serial command or IR command signal.
•Macro capability — Any button can be configured to execute multiple actions through the serial and IR control ports.
